VLX 100 Pivot Door

VLX 100 Pivot Door in Dallas, TX | Hale Windows Dallas

The VLX 100 Pivot Door is a heavy-duty aluminum door that rotates on a vertical center axis instead of side hinges, which lets it carry oversized glass panels up to 60 inches wide and 120 inches tall without sagging. It’s an architectural statement piece: clean sightlines, a dramatic swing, and enough structural integrity to stand up to Dallas heat, wind, and the occasional hailstorm. As an authorized ViewLux installation partner, Hale Windows Dallas supplies, installs, and warrants this door through one accountable team. If you’re planning a modern build or a high-end remodel anywhere from Highland Park to Frisco, call (361) 203-9040 to schedule a free on-site measurement.

Call (361) 203-9040

Product Overview – VLX 100 Pivot Door

The VLX 100 is built for homeowners and architects who want the door to be the room. Unlike a conventional hinged entry, the pivot mechanism carries the panel’s weight through the floor and header, so the door floats visually and swings with surprising ease despite its size. That’s the engineering trade-off ViewLux got right: the hardware does the heavy lifting, and the design disappears into clean vertical lines.

We see this door specified most often in Dallas neighborhoods where contemporary architecture dominates: Uptown condos, White Rock Lake mid-century renovations, and new builds in Bluffview and Preston Hollow. It suits wide entries, covered patios, and interior transitions where a standard door would feel undersized. The frame is extruded aluminum with a 2.56-inch profile width and 0.098-inch wall thickness, which gives builders real bite for anchoring into masonry or steel without adding visual bulk. Panels accept large glass lites, and the pivot system is rated for daily use in a residential setting, not occasional showroom display.

Buyers choose the VLX 100 in Dallas because they want an entry that reads as custom without the year-plus wait of a truly bespoke fabrication. Because Hale Windows Dallas is an authorized ViewLux partner, you get factory-backed product support and a local installation crew that answers the phone when something needs attention.

Technical Specifications

Here’s what the VLX 100 Pivot Door brings to a Dallas project, in plain numbers and real terms:

Tempered glass is standard practice on door panels this size around Dallas, and laminated glass is the right upgrade if you want impact resistance, sound control, or both. Hale Windows Dallas will spec the glass package based on orientation, exposure, and your neighborhood’s specific conditions.

Performance Features

Thermal Efficiency. The VLX 100 uses a thermal break between interior and exterior aluminum surfaces, which interrupts heat transfer through the frame. In a Dallas summer, that’s the difference between a door that feels warm to the touch and one that radiates heat into your entry. We pair the frame with Low-E or laminated glass options that carry NFRC-rated performance values.

Acoustic Performance. Laminated glass is a meaningful upgrade for homes near busy corridors like 75, the Tollway, or Love Field’s flight paths. The interlayer dampens mid- and high-frequency noise and reduces the hollow sound a single-pane pivot door can produce. Our Dallas clients near Preston Road traffic consistently notice the difference inside the first week.

Airtightness & Weather Seal. Every perimeter joint around the VLX 100 frame is sealed with AAMA 812 low-expansion foam, then dressed with interior trim and exterior flashing. That layered approach keeps conditioned air in and the dusty, pollen-heavy Dallas air out. It also stabilizes the frame so the pivot hardware holds its calibration over thousands of open-close cycles.

Waterproofing. Dallas sees intense spring downpours and the occasional tropical remnant. The VLX 100’s sill design channels water away from the interior floor plane, and our crew verifies weep function during final installation. The AAMA 2400/2410 installation standard we follow includes specific water-resistance testing requirements before we close a project.

Wind Resistance. A 60-inch-wide door panel catches a lot of wind. The pivot system’s top and bottom anchoring, combined with the aluminum frame’s flex characteristics, keeps the panel stable during gusty North Texas storms. Wind-load ratings are matched to Dallas-area requirements at order time, so the door you buy is engineered for the climate you actually live in.

Security & Hardware. Pivot doors need serious hardware, and the VLX 100 comes with multi-point locking options that secure the panel at the top, bottom, and latch edge. This isn’t a residential hinge door with a patio lock; the pivot geometry allows hardware configuration that would be impossible on a standard swing door.

Color & Glass Options

Six finishes keep the VLX 100 flexible across Dallas architectural styles. Premium Black is the confident choice for contemporary builds where the entry should anchor the facade. Pure White reads crisp against brick or painted masonry, a natural fit for the cleaner transitional homes going up around Lake Highlands and Casa Linda. Anodized Silver gives you the raw-aluminum look without the oxidation concerns, ideal for industrial-loft renovations in the Design District.

Bronze and Champagne suit warmer palettes and feel at home on Mediterranean or updated traditional exteriors common in Preston Hollow and Park Cities renovations. Teak Wood is a faux-wood grain finish that captures the warmth of a timber entry without the warping, splitting, or repainting that Dallas humidity cycles force on real wood doors.

Glass selection is driven by what the door faces. Clear and Low-E maximize views and light. Frosted or Obscure add privacy for entries facing the street or a neighbor. Tempered is the default safety glass; Laminated adds impact resistance and sound control. Hale Windows Dallas will walk through the options and give honest guidance for your home’s specific exposure.

Installation by Hale Windows Dallas in Dallas

Here’s the part most showrooms won’t tell you: a pivot door’s performance depends as much on installation as it does on the product. The panel tolerances are tight, the hardware is precise, and a frame set even slightly out of level will bind, scrape, or swing on its own. We see improperly installed pivot doors in Dallas homes more often than we’d like, usually from crews with good intentions but no pivot-specific training.

Our process starts with a pre-install inspection of the opening. We verify rough opening dimensions, check the condition of load-bearing supports above the door (a real concern in older Dallas houses), and confirm that the sill substrate can handle the concentrated weight of a pivot panel. Then we set the frame with shims and anchors until it is level, plumb, and square, which on a 60-inch-wide opening takes patience and a good four-foot level, not guesses.

Every perimeter joint receives AAMA 812 low-expansion foam sealant, which fills voids without distorting the frame. Flashing and sill detailing follow AAMA 2400/2410 installation standards, the same benchmark commercial glazing contractors in Dallas are held to. Before we call the job done, we run water on the exterior face, cycle the door repeatedly, and verify the hardware calibration one final time.

Improper installation voids the manufacturer’s warranty. That’s not a scare tactic; it’s standard practice in the fenestration industry. When Hale Windows Dallas installs your VLX 100, the warranty stays intact, the door performs as designed, and we’re the single point of contact if anything ever needs attention.

Frequently Asked Questions – VLX 100 Pivot Door

Get a Quote – VLX 100 Pivot Door in Dallas

If the VLX 100 Pivot Door is on your radar, let’s put real numbers on it. We’ll come to your Dallas home, measure the opening, talk through glass and finish options, and hand you a written line-item quote with no surprises. Call Hale Windows Dallas at (361) 203-9040 to schedule your free on-site measurement and project estimate.

Written by Hale Windows Dallas, authorized ViewLux installation partner serving Dallas, TX since 1991.
